Hiya's,

I have numerous pumps laying around, and an unused 100 litre plastic water butt, as far as i can find out the plastic is ok for aquatic use

Anyways, for filtration in my 6x2x2 i have an fx5 and an allpondsolutions 2000ef, also a 24w blagdon uv

Anyways i was thinking and got to testing an overflow for a sump

Thought and quickly tested the overflow with the water butt

Worked fine so it seemed

But to the crunch question

With so many here that have made their own filters, would it be better to have the butt as a kind of open top cannister filter setup or rather have a lower res of water so more like a drip filter (if this makes sense)

I thought without any real checking that if i have the overflow from the tank going into the butt through a filter sock setup with a level of water covering the top of any media, A it would be somewhat quieter and B maybe easier for a diy filter maker like myself as a first time attempt

Anyone have any input on either options ??

Would love a standard sump layout but with lack of access to store a sump under the tank i am left with a 2x2 area each side of the tank (in reality really only left side as we have a 2 door opening and if i totally block that off the missus will throw a wobbly for sure lol)

I had thought about piping up along the wall through the loft and down to a spare bedroom and using a standard shaped sump but again the missus would have a wobbly (though next year that room's getting a 8" or 9" tank built in it :) )

If no one has any input i'm leaning towards the media being fully submerged

Any thoughts please chime in

Cheers

Tony

I tried to read your post and I'm sure I will again tomarrow when it makes more sense but I couldn't get past the "water butt". (snicker)

You'll have to educate us Yanks. What the hell is a Water butt?

And this post gets my vote for the most "brit" post ever that wasn't intentionally meant to be so.

Lol

OK, a water butt for rain water collection/storage

I think across the pond you'd call it a 'Rainwater Tank' ???

Usual shape is tall round/square with a lid (i just see a massive cannister type filter though when i look at one)

Tony

ps : watertank (there ya go me ole china ;) ) it's deffo made from PP (polypropylene) so all's well

Hiya's,

A picture says a thousand words, so they say !



http://i159.photobucket.com/albums/t152/Defiance_co/Watertankfilter.jpg

Rough paint sketch

Tony

Defiance;4611814; said:
Hiya's,

A picture says a thousand words, so they say !



http://i159.photobucket.com/albums/t152/Defiance_co/Watertankfilter.jpg

Rough paint sketch

Tony

Looks like a plan to me. You'd have to seal the fittings at the bottom really well and it would be a bit of a pain to change/clean the filter media layers when needed but if you built in some handles to lift out the layers that would work very well.

That looks similar to something I've seen quite a few times. People use cheap 3 drawer chests made of plastic and fill each drawer with different filter media. each drawer has a lot of holes drilled in it and the whole thing is sitting in a tub of some sort to collect the water and pump it back up.

Your idea seems sound to me.


This guy used 550 gallon tanks in as filters for his huge tank. maybe this will give you some ideas.

http://www.monsterfishkeepers.com/forums/showthread.php?t=115444

Hiya,

Luckily the actual tap shown at the bottom comes with the watertank, sealed and tests fine :)

The tank is kinda square looking with slightly rounded corners so really any side fittings will fit flush and waterproof if needbe (a great idea on your part)

And now, what you mention about handles to lift out (circa fx-5 style) and also the drawer setup have given me an idea of incorporating both

Darn glad you replied, gave me quite a bit of help and it's much apreciated ;)

ps: That link is amazing, really gives a new meaning to 'monster filtering' lol

Many Thanks

Tony

I don't know about drawers in a top loading filter but using bent hangers or wire to be able to pull each tray out isn't a bad idea.


And JOHNPTC has the tank I want when my tank grows up. When I finally own a house I have every intention of adding on an entire fish wing to my house.

Hiya,

For wire hangers i have an idea

I have some leftover stainless odds n sods that i should be able to turn into lift-out/in handles :)

Can silver solder them easily too, so maybe go with this

Back to that monster filter setup, really give me food for thought, but obviously on a very smaller scale :( hehe

Cheers

Tony

Defiance;4614351; said:
Hiya,

For wire hangers i have an idea

I have some leftover stainless odds n sods that i should be able to turn into lift-out/in handles :)

Can silver solder them easily too, so maybe go with this

Back to that monster filter setup, really give me food for thought, but obviously on a very smaller scale :( hehe

Cheers

Tony


Not everyone can be like JOHN. lol.
